HL18-M1G3AD | Photoelectric sensors
The SICK HL18-M1G3AD is a photoelectric retro-reflective sensor featuring a dual lens system for precise detection with a sensing range up to 6.5 meters, suitable for industrial automation and safety applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18-M1G3AD | Photoelectric sensors
Brand: SICK
SKU: 1073696
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, M18 photoelectric sensor, SICK HL18 sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.03 m to 6.5 m
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Time functions: Off delay adjustable 0 to 2 seconds
- Connection: Cable open end, 2,000 mm, PVC cable
- Protection class: II
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- EMC: EN 60947-5-2 compliant
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Hybrid housing design with M18 thread diameter
- Dark switching MOSFET output with off delay adjustable from 0 to 2 seconds
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Protection class II with IP67 and IP69K enclosure rating
- Operating temperature range from -40 °C to +70 °C
- Includes fastening nut M18, plastic, black, flat
- EMC compliant with EN 60947-5-2
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper mounting, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67/IP69K rated housing reduces waste by extending product life
- Complies with China RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HL18-M1G3AD Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
