HL18L-F4A5BE | Photoelectric sensors
The SICK HL18L-F4A5BE is a compact photoelectric retro-reflective sensor designed for precise detection of small objects in industrial automation, featuring a visible red laser light and robust IP67/IP69K rated housing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18L-F4A5BE | Photoelectric sensors
Brand: SICK
SKU: 1094842
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Laser sensor, Object detection sensor, Industrial photo sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.1 m to 10 m (max 12 m)
- Light source: Visible red laser, wavelength 655 nm, Laser class I
- Switching output: Push-pull PNP/NPN complementary outputs with light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Male M12, 4-pin connector
- Housing material: Plastic VISTAL®, Optics material: Plastic PMMA
- Protection class: III, Enclosure rating: IP67 and IP69K
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Electromagnetic compatibility: EN 60947-5-2
- Dimensions (H x L x W): 48.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red laser light source with 655 nm wavelength
- Sensing range from 0.1 m to 10 m (max 12 m)
- Signal strength light bar for easy adjustment
- Light/dark switching with potentiometer adjustment
- Push-pull PNP/NPN complementary switching outputs
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing with IP67 and IP69K protection ratings
- Operating temperature range from -30 °C to +55 °C
- Male M12 4-pin connector with plastic PVC cable material
- Electromagnetic compatibility compliant with EN 60947-5-2
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper alignment and secure mounting using the supplied M18 fastening nut.
Applications
- Industrial automation for detecting small objects
- Material handling and packaging systems
- Quality control and inspection processes
- Robotics and conveyor systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable housing reduces waste by extending product lifespan
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HL18L-F4A5BE Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
