HL18L-P1G5BA | Photoelectric sensors
The SICK HL18L-P1G5BA is a high-performance photoelectric retro-reflective sensor designed for precise detection of small objects in industrial automation environments, featuring a robust IP67/IP69K rated housing and laser light source.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18L-P1G5BA | Photoelectric sensors
Brand: SICK
SKU: 1071027
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Laser sensor, Industrial object sensor, SICK HL18L sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.1 m to 12 m
- Light source: Visible red laser, 655 nm wavelength, Laser class I
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: Complementary PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable open end, 2,000 mm PVC cable
- Protection class: III
- Enclosure rating: IP67, IP69K
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red laser light source with 655 nm wavelength
- Sensing range from 0.1 m up to 12 m
- Signal strength light bar for easy adjustment
- IP67 and IP69K rated for robust protection
- Plastic VISTAL® housing with blue color
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Complementary PNP switching outputs with light/dark switching modes
- Polarizing filter included to reduce interference
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- Small object detection in manufacturing lines
- Safety and control systems requiring precise sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67/IP69K housing reduces need for frequent replacements, minimizing waste
- Low power consumption with efficient laser light source
- Compliance with China RoHS ensures reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HL18L-P1G5BA Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
