Horizontal Liquid Receiver 309-45-H | 45L Volume | ISO/AS 5149.2 Compliant | Anti-Corrosion Finish | by Aspen Pumps
The Horizontal Liquid Receiver 309-45-H is designed for efficient refrigerant storage in commercial and industrial HVAC systems. With a 45-liter volume and compliance with ISO/AS 5149.2 standards, it minimizes refrigerant leakage and pressure drop, enhancing plant efficiency. Ideal for professionals seeking reliable pressure vessel solutions, this receiver features solid copper connections and an anti-corrosion finish for extended lifespan.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Horizontal Liquid Receiver 309-45-H | 45L Volume | ISO/AS 5149.2 Compliant | Anti-Corrosion Finish | by Aspen Pumps
Brand: Aspen Pumps
SKU: 309-45-H
Alternatively Known As: Horizontal Refrigerant Receiver, Liquid Refrigerant Receiver, HVAC Liquid Receiver, Refrigeration Pressure Vessel
Technical Specifications
- Connection size: 1 3/4 R/L X 1 3/4 R/L
- Volume: 45 liters
- Height: 900 mm
- Diameter: 273 mm
- Safe Working Pressure (SWP): 3,300 kPa
- Manufactured to ISO/AS 5149.2 standards
- Anti-corrosion powder coat finish
- Solid copper connections
- Includes liquid level switch port on large vertical receivers
- Harmonic wave cut design to reduce noise
- Oil drain channels to prevent oil logging
- Dimensions (H x L x W): 900mm x 600mm x 273mm
- Weight: 15 kg
Key Features
- Connection: 1 3/4 R/L X 1 3/4 R/L
- Volume: 45L
- Manufactured in accordance with ISO/AS 5149.2
- Safe working pressure (SWP) of 3,300 kPa
- Minimal pressure drop to improve plant efficiency
- SKY safety socket fitted with PRV socket to prevent refrigerant leakage
- Anti-corrosion powder coat finish with solid copper connections
- Receivers with rotalock connection not supplied with valves
- Large vertical receivers include liquid level switch port
- Compatible with 1 1/4 rotalock sightglass with liquid level switch adaptor 412-202020
- Harmonic wave cut principles reduce noise and smooth discharge pulse
- Oil drain channels prevent oil logging
Professional Installation Requirements
- Installation must be performed by qualified HVAC or refrigeration professionals in compliance with local regulations and safety standards.
Applications
- Refrigeration systems requiring liquid refrigerant storage
- Commercial and industrial HVAC systems
- Plants requiring efficient refrigerant management and pressure vessel solutions
Standards & Compliance
- Complies with AS/NZS 5149.2 for Refrigeration Systems and Heat Pumps
Environmental Benefits
- Minimizes refrigerant leakage with safety socket design
- Improves plant efficiency by reducing pressure drop
- Anti-corrosion finish extends product lifespan, reducing waste
Warranty Information
Warranty details available upon request from Aspen Pumps, typically covering manufacturing defects.
Available Now
The Aspen Pumps Horizontal Liquid Receiver 309-45-H is available for immediate purchase, ideal for commercial and industrial refrigeration and HVAC applications.
