Trade Discount 17%
Horizontal Liquid Receiver 309-60-H | 60L Volume | Anti-Corrosion Finish | SWP 3,300 kPa | by Aspen Pumps
The Horizontal Liquid Receiver 309-60-H is designed for efficient refrigerant storage in industrial and commercial HVAC systems. With a 60L volume and a safe working pressure of 3,300 kPa, it features solid copper connections and an anti-corrosion powder coat finish. Ideal for refrigeration systems, this receiver minimizes refrigerant leakage and enhances plant efficiency, making it a reliable choice for professionals.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Horizontal Liquid Receiver 309-60-H | 60L Volume | Anti-Corrosion Finish | SWP 3,300 kPa | by Aspen Pumps
Brand: Aspen Pumps
SKU: 309-60-H
Alternatively Known As: Horizontal Refrigerant Receiver, Liquid Refrigerant Receiver, HVAC Liquid Receiver, Refrigeration Liquid Receiver
Technical Specifications
- Connection Size: 1 3/4 R/L X 1 3/4 R/L
- Volume: 60 Litres
- Height: 1200 mm
- Diameter: 273 mm
- Safe Working Pressure (SWP): 3,300 kPa
- Manufactured to ISO/AS 5149.2 standards
- Anti-corrosion powder coat finish
- Solid copper connections
- Oil drain channels to prevent oil logging
- Dimensions (H x L x W): 1200mm x 600mm x 273mm
- Weight: 25 kg
Key Features
- Connection: 1 3/4 R/L X 1 3/4 R/L
- Volume: 60L
- Manufactured in accordance with ISO/AS 5149.2
- SWP of 3,300 kPa
- Minimal pressure drop to improve plant efficiency
- SKY safety socket fitted with PRV socket to prevent refrigerant leakage
- Anti-corrosion powder coat finish
- Solid copper connections
- Oil drain channels to prevent oil logging
- Large vertical receivers have liquid level switch port
- Compatible with 1 1/4 rotalock sightglass with adaptor 412-202020
Professional Installation Requirements
- Installation should be performed by qualified HVAC or refrigeration professionals to ensure compliance with safety and operational standards.
Applications
- Refrigeration systems requiring liquid refrigerant storage
- Industrial and commercial HVAC systems
- Plants requiring efficient refrigerant management
Standards & Compliance
- Complies with AS/NZS 5149.2 for Refrigeration Systems and Heat Pumps
Environmental Benefits
- Minimizes refrigerant leakage with SKY safety socket to reduce environmental impact
- Improves plant efficiency by reducing pressure drop, lowering energy consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to Aspen Pumps warranty policy for details.
Available Now
The Aspen Pumps Horizontal Liquid Receiver 309-60-H is available for immediate purchase, ideal for refrigeration and HVAC system applications.
