Hot Dip Galvanised Steel Wire Cable Tray | U-Shape Profile | 150mm Width | Corrosion Resistant | @Each of 1 | by Cablofil
The Hot Dip Galvanised Steel Wire Cable Tray is designed for effective cable management in industrial, commercial, and residential settings. With a robust U-shape profile and superior corrosion resistance, it supports and routes electrical cables efficiently. Ideal for both indoor and outdoor use, this tray ensures optimal cable performance and longevity, making it a reliable choice for any installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hot Dip Galvanised Steel Wire Cable Tray | U-Shape Profile | 150mm Width | Corrosion Resistant | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: CM000033
Alternatively Known As: Galvanised Steel Cable Tray, Wire Mesh Cable Tray, Hot Dip Galvanised Cable Tray, Steel Wire Cable Tray 150x30
Technical Specifications
- Profile shape: U-shape
- Width: 150 mm
- Height: 30 mm
- Length: 3000 mm
- Usable cross section: 3978 mm²
- Material: Steel
- Surface protection: Hot-dip galvanised
- Colour: Zinc
- Weight: 0.71 kg/m
- Operating temperature: -20°C to 120°C
- Storage temperature: -20°C to 120°C
- Model: Without connector
- Suitable for circuit integrity: No
- Dimensions (H x L x W): 30mm x 3000mm x 150mm
- Weight: 2.13 kg
Key Features
- Unique T-welded safety edge protects cables and installers
- Natural ventilation provides greater cable efficiency
- Hot-dip galvanised steel construction for superior corrosion resistance
- U-shaped profile for robust cable support
- Operating temperature range from -20°C to 120°C
Professional Installation Requirements
- Professional installation by qualified electricians or cable management specialists is recommended to ensure compliance with electrical safety standards and optimal cable support.
Applications
- Cable management in industrial, commercial, and residential electrical installations
- Support and routing of electrical cables in data centers, manufacturing plants, and infrastructure projects
- Suitable for indoor and outdoor use due to corrosion-resistant galvanised finish
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Hot-dip galvanising extends product lifespan reducing replacement frequency and waste
- Steel is recyclable, supporting sustainable material use
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil or Legrand for specific warranty details.
Available Now
The Cablofil Hot Dip Galvanised Steel Wire Cable Tray 150mm x 30mm x 3m Length is available for immediate purchase, ideal for industrial, commercial, and residential cable management applications.
