Hour Counter 22mm | Digital Display | IP65 Rated | Non-Resettable | @Pack of 1 | by Clipsal
The Hour Counter 22mm is a digital hour meter designed for industrial applications, featuring a robust construction and an easy-to-read display. With a voltage range of 24-240V AC/DC and IP65 front protection, it's perfect for monitoring machinery and control panels. Ideal for proactive maintenance, this hour counter ensures efficient energy use and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hour Counter 22mm | Digital Display | IP65 Rated | Non-Resettable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHXB5DSM
Alternatively Known As: Panel Mount Hour Meter, Digital Hour Counter, Industrial Hour Meter, Clipsal Hour Meter, 22mm Hour Counter
Technical Specifications
- Mounting diameter: 22mm
- Display: Digital hour counter
- Voltage: 24-240V AC/DC
- Frequency: 50/60Hz
- Operating temperature: -20°C to +55°C
- Front protection: IP65
- Reset: Non-resettable
- Connection: Screw terminal
- Dimensions (H x L x W): 30mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- Panel mount hour counter with 22mm diameter
- Easy-to-read digital display
- Long-life, maintenance-free operation
- Suitable for AC and DC voltages
- Robust construction for industrial environments
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Industrial machinery monitoring
- Control panels
- Generators
- Pumps
- Compressors
- Process equipment
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables proactive maintenance, reducing unnecessary equipment replacement and waste.
- Supports efficient energy use by monitoring operational hours.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHXB5DSM Hour Counter 22mm is available for immediate purchase. Ideal for industrial control panels and machinery monitoring.
