HPM 3P 65A 415V AC Back Entry Surface Mount Mains Switch | Heavy-Duty Silver Contacts | Lockable Isolation | @EA of 1 | by HPM
The HPM 3P 65A 415V AC Back Entry Surface Mount Mains Switch is designed for reliable electrical power control in industrial and commercial applications. Featuring heavy-duty double-break silver contacts and a convenient back entry design, this switch ensures safe isolation and easy access for maintenance. Ideal for licensed electricians, it complies with AS/NZS 3000 standards, making it a durable and safe choice for three-phase systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HPM 3P 65A 415V AC Back Entry Surface Mount Mains Switch | Heavy-Duty Silver Contacts | Lockable Isolation | @EA of 1 | by HPM
Brand: HPM
SKU: B365
Alternatively Known As: 3 Pole Main Switch, Surface Mount Mains Switch, Lockable Mains Isolator Switch
Technical Specifications
- Rated Current: 65A
- Voltage: 415V AC
- Poles: 3P
- Contact Type: Heavy-duty double-break silver contacts
- Terminal Type: Tunnel-type clamping terminals on line and load sides
- Mounting: Surface mount with back entry wiring
- Padlock Provision: Accepts padlock up to Ø5mm
- Mounting Hole Centres: 60 x 16mm
- Dimensions (H x L x W): 205mm x 160mm x 205mm
- Weight: 2.25 kg
Key Features
- Heavy-duty, double-break silver contacts for enhanced durability and performance
- Tunnel-type clamping terminals on both line and load sides
- Back entry design for convenient wiring
- Provision for padlock insertion (up to Ø5mm) for lockable isolation
- Mounting holes at top right and bottom left corners with 60 x 16mm centres
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with electrical safety standards and proper connection.
Applications
- Industrial and commercial electrical distribution systems
- Surface mounting for easy access in electrical panels
- Safe isolation and control of electrical power in three-phase systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces the need for frequent replacements, minimizing waste
- Lockable isolation enhances safety, preventing accidental power usage and potential damage
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The HPM 3P 65A 415V AC Back Entry Surface Mount Mains Switch is available for immediate purchase, ideal for industrial and commercial electrical power control applications.
