Trade Discount 20%
HSS AlCrN SMART STEP Stepped Drill Bit | 6-30 mm Diameter | AlTiN Coating | 3-Flat Shank | by Wurth
The HSS AlCrN SMART STEP stepped drill bit is designed for precision drilling in various materials, including steel, stainless steel, and plastic. With an innovative geometry for faster spot drilling and a durable AlTiN coating, this bit ensures optimal chip removal and longevity. Ideal for machining tasks, it offers a reliable solution for professionals seeking efficiency and performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HSS AlCrN SMART STEP Stepped Drill Bit | 6-30 mm Diameter | AlTiN Coating | 3-Flat Shank | by Wurth
Brand: Wurth
SKU: 694451630
Alternatively Known As: Stepped drill bit, Step drill bit, SMART STEP drill bit, HSS step drill, AlTiN coated drill bit
Technical Specifications
- Min./max. drill diameter: 6-30 mm
- Shank diameter: 10 mm
- Shaft length: 24 mm
- Overall length: 97 mm
- Shank style: 3-face shank
- Surface coating: AlTiN multi-layer
- Type description: HSS AlCrN SMART STEP
- Material compatibility: Steel, Cast metal, Stainless steel, Non-ferrous metal, Plastic, Wood
- Dimensions (H x L x W): 97mm x 97mm x 10mm
- Weight: 0.1 kg
Key Features
- Innovative geometry with three chip surfaces between step transitions for up to 3x longer service life and faster drilling
- SMART STEP technology enables up to 3x faster spot drilling without centring or centre-punching
- Deep-ground spiral flute with high temperature resistance up to 1150°C and high coating hardness of 3200 HV
- AlTiN multi-layer wear protection coating for optimal chip removal and improved cutting properties
- 3-flat shank prevents spinning in the drill chuck and ensures optimal power transmission
- Product packaging made from 100% PCR recycled plastic and is fully recyclable
Professional Installation Requirements
- No professional installation required; suitable for use with standard drill chucks by trained operators.
Applications
- Drilling in steel, cast metal, stainless steel, non-ferrous metal, plastic, and wood
- Machining tasks requiring precise and fast spot drilling
- Sheet metal drilling up to 3.5 mm thickness
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Packaging made from 100% post-consumer recycled plastic and is fully recyclable
- Durable coating and design extend tool life, reducing waste
Warranty Information
Wurth provides a standard warranty against manufacturing defects; please refer to Wurth's official warranty policy for details.
Available Now
The Wurth HSS AlCrN SMART STEP stepped drill bit is available for immediate purchase, ideal for machining and metalworking applications requiring precision and durability.
