HSS Core Drill Bit | High-Speed Steel | Weldon Shank | 30mm Cutting Depth | by Wurth
The HSS Core Drill Bit is designed for high-performance drilling in steel, aluminum, and wood. With a cutting depth of 30mm and a Weldon shank, it ensures precise guidance and rapid drilling progress without the need for pre-drilling. Ideal for professionals, this drill bit offers a long service life and optimized cutting geometry for clean profiles, making it perfect for large through-holes in various materials.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HSS Core Drill Bit | High-Speed Steel | Weldon Shank | 30mm Cutting Depth | by Wurth
Brand: Wurth
SKU: 630930
Alternatively Known As: HSS Core Drill Bit, High-Speed Steel Core Drill, Metal Core Drill Bit, Weldon Shank Drill Bit
Technical Specifications
- Material to be processed: Steel, Aluminium, Wood
- Cutting material: HSS (High-Speed Steel)
- Cutting depth: 30 mm
- Length: 64.2 mm
- Shank style: Weldon
- Surface: Plain
- Number of pieces in set: 7 PCS
- Quality: Wurth-Standard
- Service life rating: 2 of 4 points
- Drilling speed rating: 3 of 4 points
- Bore hole quality rating: 4 of 4 points
- Versatility rating: 2 of 4 points
- Drilling behaviour rating: 3 of 4 points
- Dimensions (H x L x W): 64mm x 64mm x 30mm
- Weight: 0.2 kg
Key Features
- High performance and rapid drilling progress with a long service life
- No pre-drilling required and no formation of burrs
- Optimised cutting geometry for clean drill profile and precise tolerances
- Precise guidance with no slipping, drilling only a thin ring of material
- Core drills are up to 10 times quicker than twist drills
- Requires continuous cooling during drilling to increase service life
- Not suitable for pressboard, titanium, or heat-resistant and high-alloy steels
Professional Installation Requirements
- Use with appropriate drilling machines only. Core drills must not be used hand-guided. Ensure perfect concentricity and correct clamping of the tool drive. Use continuous cooling and wear protective equipment including eye, hearing protection, and gloves.
Applications
- Drilling large through-holes up to 50 mm diameter in conventional steels up to 850 N/mm²
- Suitable for wood and non-ferrous metals such as aluminium, aluminium alloys, and plastics
- Use with mobile magnetic or stationary drilling machines
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long service life reduces the frequency of tool replacement and waste
- Efficient drilling reduces energy consumption during machining
Warranty Information
Wurth standard warranty applies. Please refer to Wurth's warranty policy for details.
Available Now
The Wurth Standard HSS Core Drill Bit is available for immediate purchase. Ideal for machining large through-holes in steel, aluminium, wood, and plastics.
