HTB18-B1G2BH | Photoelectric sensors
The SICK HTB18-B1G2BH is a high-performance photoelectric proximity sensor featuring background suppression, suitable for precise object detection in industrial automation with robust IP67/IP69K protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18-B1G2BH | Photoelectric sensors
Brand: SICK
SKU: 1080300
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, M18 photoelectric sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 150 mm standard, up to 300 mm extended
- Light source: Visible red PinPoint LED, wavelength 631 nm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP and NPN light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable open end, 2,000 mm, PVC
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +65 °C
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light PinPoint LED with 631 nm wavelength
- Sensing range from 5 mm to 150 mm (standard) and up to 300 mm (extended)
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy adjustment
- Light/dark switching with potentiometer adjustment
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- IP67 and IP69K rated for robust protection against dust and water
- Wide operating temperature range from -40 °C to +65 °C
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation by a qualified electrician or trained technician is recommended to ensure proper wiring and sensor alignment for optimal performance and safety.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and presence detection in machinery
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K housing reduces waste by extending product life
- Complies with China RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-B1G2BH Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
