HTB18-L1G2AF | Photoelectric sensors
The SICK HTB18-L1G2AF photoelectric sensor features background suppression technology, robust IP67/IP69K rated housing, and adjustable sensing range, ideal for precise object detection in industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18-L1G2AF | Photoelectric sensors
Brand: SICK
SKU: 1078475
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, M18 photoelectric sensor, Industrial object sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 150 mm (standard), up to 300 mm (max)
- Light source: Visible red PinPoint LED, wavelength 631 nm
- Switching output: MOSFET, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Connection: Cable open end, 2,000 mm PVC cable, conductor cross section 0.2 mm²
- Protection class: II
- Enclosure rating: IP67, IP69K
- Housing material: Plastic (VISTAL®), optics material: Plastic (PMMA)
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light PinPoint LED light source
- Adjustable sensing range and on delay via potentiometers
- High switching frequency up to 1,000 Hz
- Robust plastic housing with IP67 and IP69K protection ratings
- Wide supply voltage range: 21.6 V DC to 250 V DC and 96 V AC to 250 V AC
- Fast response time of ≤ 0.5 ms
- MOSFET switching output with light switching mode
- Cable open end connection with 2,000 mm PVC cable
- Operating temperature range from -40 °C to +65 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation with low current consumption (≤ 10 mA)
- Durable design reduces waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-L1G2AF photoelectric sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
