HTB18-M1G2AAD02 | Photoelectric sensors
The SICK HTB18-M1G2AAD02 is a reliable photoelectric proximity sensor featuring background suppression, suitable for industrial automation and object detection with robust IP67/IP69K rated housing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18-M1G2AAD02 | Photoelectric sensors
Brand: SICK
SKU: 1077796
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, M18 photoelectric sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range max: 5 mm to 300 mm
- Light source: Visible red PinPoint LED, wavelength 631 nm
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤10 mA
- Switching output: MOSFET, dark switching
- Output current max: ≤100 mA
- Response time: ≤0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable open end, 2,000 mm PVC cable
- Protection class: II
- Enclosure rating: IP67, IP69K
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Ambient operating temperature: -40 °C to +65 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 46mm x 34mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Hybrid housing design with M18 thread diameter
- Sensing range from 5 mm to 300 mm
- Visible red light source with PinPoint LED
- High switching frequency of 1,000 Hz
- MOSFET dark switching output with max 100 mA output current
- Robust plastic VISTAL® housing with IP67 and IP69K protection
- Wide ambient operating temperature range from -40 °C to +65 °C
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection according to industrial safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤10 mA current draw
- Durable design reduces waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HTB18-M1G2AAD02 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
