HTB18-N1G2BB | Photoelectric sensors
The SICK HTB18-N1G2BB is a reliable photoelectric proximity sensor featuring background suppression, suitable for precise object detection in industrial automation with robust IP67/IP69K protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18-N1G2BB | Photoelectric sensors
Brand: SICK
SKU: 1073430
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, M18 photoelectric sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 150 mm (standard), up to 300 mm max
- Light source: PinPoint LED, visible red light, 631 nm wavelength
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: NPN complementary, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable open end, 2,000 mm PVC cable
- Protection class: III
- Enclosure rating: IP67, IP69K
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 46mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light PinPoint LED with 631 nm wavelength
- Sensing range from 5 mm to 150 mm (standard), up to 300 mm max
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy adjustment
- NPN complementary switching output with light/dark switching modes
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing with IP67 and IP69K protection ratings
- Wide ambient operating temperature range from -40 °C to +65 °C
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with photoelectric sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Material handling and packaging systems
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤ 20 mA current draw
- Durable housing reduces waste through extended product life
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-N1G2BB Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
