HTB18-P4B2BAD04 | Photoelectric sensors
The SICK HTB18-P4B2BAD04 is a photoelectric proximity sensor featuring background suppression, designed for precise object detection in industrial automation with robust IP67/IP69K protection and fast switching.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18-P4B2BAD04 | Photoelectric sensors
Brand: SICK
SKU: 1079040
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, M18 photoelectric sensor, SICK proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 5 mm to 150 mm (preset 100 mm)
- Light source: Visible red PinPoint LED, wavelength 631 nm
- Switching output: Complementary PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Current consumption: ≤ 20 mA
- Connection: Cable with M12 male connector, 4-pin, 150 mm
- Housing material: Plastic VISTAL®, optics material: PMMA
- Protection class: III, Enclosure rating: IP67, IP69K
- Operating temperature: –40 °C to +65 °C
- Storage temperature: –40 °C to +75 °C
- EMC compliance: EN 60947-5-2, Radio Safety Class A
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red light PinPoint LED with 631 nm wavelength
- Sensing range preset to 100 mm with signal strength light bar
- Hybrid housing design with M18 thread diameter
- Light/dark switching mode with complementary PNP outputs
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing and PMMA optics
- Protection rating IP67 and IP69K for harsh environments
- Wide operating temperature range from –40 °C to +65 °C
- Cable with M12 male connector, 4-pin, 150 mm length
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in machinery
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable design reduces waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18-P4B2BAD04 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
