HTB18L-P2B5BB | Photoelectric sensors
The SICK HTB18L-P2B5BB is a photoelectric proximity sensor featuring background suppression, visible red laser light, and robust IP67/IP69K rated housing, ideal for precise detection of small objects in industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTB18L-P2B5BB | Photoelectric sensors
Brand: SICK
SKU: 1104069
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, Laser proximity sensor, M18 photoelectric sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with background suppression
- Sensing range: 30 mm to 250 mm (max 300 mm)
- Light source: Visible red laser, 655 nm wavelength, Laser class I
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Current consumption: ≤ 20 mA
- Switching output: PNP, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with M8 3-pin connector, 150 mm length
- Housing material: Plastic VISTAL®, optics material: PMMA
- Protection class: III
- Enclosure rating: IP67 and IP69K
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- EMC: EN 60947-5-2 compliant
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible red laser light source with 655 nm wavelength
- Sensing range from 30 mm to 250 mm (max 300 mm)
- Signal strength light bar for easy adjustment
- Hybrid housing design with M18 thread diameter
- IP67 and IP69K rated for dust and water protection
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Cable with M8 3-pin connector, 150 mm length
- Electromagnetic compatibility compliant with EN 60947-5-2
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment, secure mounting, and correct electrical connections according to manufacturer guidelines.
Applications
- Industrial automation for detecting small objects
- Manufacturing process control
- Material handling and packaging systems
- Robotics and assembly lines requiring precise object detection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K rated housing reduces need for frequent replacements
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTB18L-P2B5BB Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
