HTE18-P1G2BB | Photoelectric sensors
The SICK HTE18-P1G2BB is a durable photoelectric proximity sensor featuring a hybrid M18 housing, visible red PinPoint LED light source, and high switching frequency, ideal for industrial automation and safety applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTE18-P1G2BB | Photoelectric sensors
Brand: SICK
SKU: 1074756
Alternatively Known As: Photoelectric proximity sensor M18, SICK photo sensor, PNP photoelectric sensor, Industrial proximity sensor, Red light photo sensor
Technical Specifications
- Functional principle: Energetic photoelectric proximity sensor
- Sensing range: 10 mm to 200 mm (max 600 mm)
- Light source: Visible red PinPoint LED, wavelength 631 nm
- Switching output: PNP complementary outputs (Light and Dark switching)
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Current consumption: ≤ 20 mA
- Connection: Cable open end, 2,000 mm, PVC cable
- Protection class: III
- Enclosure rating: IP67 and IP69K
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Operating temperature: –40 °C to +70 °C
- Storage temperature: –40 °C to +75 °C
- EMC compliance: EN 60947-5-2, Radio Safety Class A
- Dimensions (H x L x W): 46mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Hybrid housing design with M18 thread diameter
- Sensing range from 10 mm to 200 mm (max 600 mm)
- Visible red light source with PinPoint LED
- Signal strength light bar for easy adjustment
- Light/dark switching mode with complementary PNP outputs
- High switching frequency of 1,000 Hz and fast response time ≤ 0.5 ms
- Robust plastic VISTAL® housing with IP67 and IP69K protection
- Wide ambient operating temperature range from –40 °C to +70 °C
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper mounting, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K rated housing reduces waste by extending product life
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HTE18-P1G2BB Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
