HTF18-P3A2BB | Photoelectric sensors
The SICK HTF18-P3A2BB is a high-performance photoelectric proximity sensor featuring foreground suppression, robust IP67/IP69K rated housing, and fast switching for industrial automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HTF18-P3A2BB | Photoelectric sensors
Brand: SICK
SKU: 1078491
Alternatively Known As: Photoelectric proximity sensor, Foreground suppression sensor, M18 photoelectric sensor, Red light proximity sensor
Technical Specifications
- Functional principle: Photoelectric proximity sensor with foreground suppression
- Sensing range: 5 mm to 300 mm
- Light source: PinPoint LED, visible red light, 631 nm wavelength
- Switching output: Complementary PNP, light/dark switching
- Max output current: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Connection: Male connector M8, 4-pin
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +65 °C
- Storage temperature: -40 °C to +75 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 44.9mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with foreground suppression
- Visible red light PinPoint LED with 631 nm wavelength
- Sensing range from 5 mm to 300 mm
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy adjustment
- Light/dark switching mode with complementary PNP outputs
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing and PMMA optics
- Protection rating IP67 and IP69K for harsh environments
- Wide ambient operating temperature range from -40 °C to +65 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and presence detection in machinery
- Packaging and material handling systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K rated housing reduces waste by extending product life
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK HTF18-P3A2BB Photoelectric Proximity Sensor is available for immediate purchase. Ideal for industrial automation and safety applications requiring reliable object detection.
