Illuminated Push Button Head | Universal LED | Spring Return | IP69K Rated by Clipsal
Illuminated push button head with universal LED compatibility and spring return—ideal for industrial control panels and machinery. Built for durability, with IP69K rating for high protection against dust and water.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony XB4, Head for illuminated push-button, metal, orange flush, 22mm, universal LED, spring return, plan lens
Brand: Clipsal
SKU: ZB4BW353
Alternatively Known As: Illuminated Push Button Head, XB4 Push Button, Harmony Push Button
Technical Specifications
- Mechanical durability: 10,000,000 cycles
- Ambient air temperature for operation: -40...70 °C
- Resistance to high pressure washer: 7,000,000 Pa at 55 °C
- Overvoltage category: Class I conforming to IEC 60536
- Vibration resistance: 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6
- Shock resistance: 30 gn (duration = 18 ms) conforming to IEC 60068-2-27
- Dimensions (H x L x W): 29mm x 30mm x 29mm
- Weight: 0.026 kg
Key Features
- Illuminated push-button head with universal LED compatibility.
- Spring return mechanism for reliable operation.
- IP66, IP67, IP69K rated for high protection against dust and water.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Industrial: Control panels, machinery, automation systems
Standards & Compliance
- Complies with UL 508, IEC 60947-5-5, and other relevant standards.
Environmental Benefits
- Packaging made with recycled cardboard and without single-use plastic.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Harmony XB4 Head for illuminated push-button is available now for immediate purchase. Ideal for industrial control applications.
