Illuminated Push Button Switch | 2-Position Push-Pull Operation | Mushroom Head Design | 24V AC/DC | by Allen-Bradley
The Illuminated Push Button Switch by Allen-Bradley features a 2-position push-pull operation and a clear mushroom head design for enhanced visibility. Ideal for industrial control panels and machinery operation, this robust button operates at 24V AC/DC and includes terminal guards for added safety. Built for durability, it’s perfect for emergency stop and start functions in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Type: Push Button
- Operation: 2-position push-pull
- Head Style: Mushroom head (push-pull)
- Illumination: Incandescent
- Voltage: Full voltage - 24V AC/DC
- Protection: Type 4/13
- Terminal Guards: Included
- No Cap: Standard - 1 NCLB
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.3 kg
Key Features
- 2-position push-pull operation
- Illuminated mushroom head for clear visibility
- Metal construction with Type 4/13 protection
- Guards on terminals for safety
- Push-pull/twist mechanism
- Incandescent illumination
- Full voltage operation at 24V AC/DC
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- Industrial control panels
- Machinery operation
- Emergency stop and start functions
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long-lasting incandescent illumination reduces frequent replacements
- Robust metal construction minimizes waste through durability
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXTQ24XD4 Illuminated Push Button is available for immediate purchase, ideal for industrial and commercial control panel applications.
