Illuminated Push Button Switch | 30.5 mm Mushroom Head | 3-Position Operation | 120V AC | by Allen-Bradley
The Illuminated Push Button Switch features a 30.5 mm mushroom head and a versatile 3-position operation (momentary-maintained-maintained), making it ideal for industrial control panels and machinery operation interfaces. With its durable metal construction and energy-efficient incandescent transformer at 120V AC, this push-pull button ensures reliable performance in automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Button Diameter: 30.5 mm
- Operation: 3-position push-pull (momentary-maintained-maintained)
- Illumination: Incandescent transformer, 120V AC 50/60 Hz
- Material: Metal with Type 4/13 terminal guards
- Contact Configuration: 1 Normally Closed, 1 Normally Open
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.3 kg
Key Features
- 30.5 mm mushroom head push-pull button
- 3-position operation: momentary-maintained-maintained
- Illuminated with incandescent transformer at 120V AC 50/60 Hz
- Metal construction with Type 4/13 guards on terminals
- Standard contact configuration: 1 NCLB 1 NC
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Industrial control panels
- Machinery operation interfaces
- Automation systems requiring push-pull control
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces replacement frequency and waste
- Energy-efficient incandescent transformer for illumination
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXMP16RA7 Illuminated Push Button is available for immediate purchase, ideal for industrial and automation control applications.
