Illuminated Push-Pull Mushroom Head Push Button | 2-Position Operation | 30.5mm Diameter | Red Emergency Signaling | by Allen-Bradley
The Illuminated Push-Pull Mushroom Head Push Button is designed for industrial control applications, featuring a 2-position push-pull mechanism and a 30.5mm diameter mushroom head for clear visibility. With a durable metal construction and Type 4/13 enclosure rating, it ensures reliable operation in harsh environments, making it ideal for machinery operation and safety in automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- 2-position push-pull mechanism
- 30.5 mm mushroom head diameter
- Illuminated with incandescent lamp
- Full voltage operation at 24V AC/DC
- Type 4/13 enclosure rating
- Terminal guards included
- Red color for emergency signaling
- Standard 2 Normally Closed/Normally Open contacts
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.3 kg
Key Features
- 2-position push-pull operation
- Illuminated mushroom head for clear visibility
- Metal construction for durability
- Type 4/13 rated for protection against dust and water
- Guards on terminals for safety
- Incandescent illumination
- Full voltage operation at 24V AC/DC
- Red color for emergency or stop functions
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper wiring.
Applications
- Industrial control panels
- Machinery operation and safety
- Automation systems requiring illuminated push buttons
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces replacement frequency and waste
- Incandescent illumination designed for efficient low voltage operation
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXQ24RA5 Illuminated Push-Pull Mushroom Head Push Button is available for immediate purchase, ideal for industrial and automation control applications.
