Impulse Relay 2P 16A | Remote & Manual Control | DIN Rail Mount by Clipsal
Impulse relay with 2P 16A capacity and remote/manual control—ideal for small commercial and residential applications. Built for versatility, with illuminated push-button and DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated current: 16 A
- Rated operational voltage: 250 V AC 50/60 Hz
- Control type: remote and manual control
- Control signal type: impulse
- Electrical durability: AC-21: 200000 cycles, AC-22: 100000 cycles
- IP degree of protection: IP20 (on opening), IP40 (in enclosure)
- Ambient air temperature for operation: -20...50 °C
- Ambient air temperature for storage: -40...70 °C
- Noise level: 60 dB
- Pollution degree: 3
- Tropicalisation: 2
- Dimensions (H x L x W): 84mm x 60mm x 18mm
- Weight: 0.111 kg
Key Features
- Impulse relay with remote and manual control
- Illuminated push-button control
- DIN rail mounting
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Small commercial and residential applications
Standards & Compliance
- Complies with EN 669-1 and EN 669-2-2 standards.
Environmental Benefits
- Complies with environmental standards and regulations.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Impulse Relay iTL 2P 16A is available now for immediate purchase. Ideal for small commercial and residential applications.
