Incremental Encoder 2 Inch Diameter | Solid Shaft | 360 PPR | by Allen-Bradley
The Incremental Encoder with a 2-inch diameter solid shaft is perfect for industrial automation and control systems. Operating on an 8-30 VDC power supply, it features a standard square flange mounting and provides 360 pulses per revolution (PPR) for precise feedback. Ideal for robotics, conveyor systems, and motor control, this encoder ensures reliable performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Diameter: 2 inches
- Shaft type: Solid shaft
- Mounting: Standard square flange
- Power supply: 8-30 VDC
- Output: Radial exit
- Connector: MS 6-pin with mating connector
- Pulse rate: 360 pulses per revolution (PPR)
- Rotation: Clockwise (CW)
- Signal: B leads A, Z gated with BN
- Dimensions (H x L x W): 50mm x 50mm x 50mm
- Weight: 0.5 kg
Key Features
- Incremental encoder with 2 inch diameter solid shaft
- Standard square flange mounting
- Operates on 8-30 VDC power supply
- Radial exit with MS 6-pin connector and mating connector
- 360 pulses per revolution (PPR)
- CW rotation with B leads A and Z gated with BN
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and operation.
Applications
- Industrial automation and control systems
- Robotics and machinery position feedback
- Conveyor systems and motor control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 8-30 VDC operation
- Durable design reduces replacement frequency and waste
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 847TDN2CRC00360 Incremental Encoder is available for immediate purchase, ideal for industrial automation and control applications.
