Incremental Encoder Cable M23 12-Pin | IP66/IP67 Rated | 5m PUR Jacket | by SICK
The Incremental Encoder Cable M23 12-Pin is designed for reliable signal transmission in industrial automation systems. Featuring female and male connectors, a durable 5m PUR jacket, and IP66/IP67 rating for dust and water protection, this cable ensures optimal performance in machine control and monitoring applications. Built to withstand temperatures from -20°C to +130°C, it’s perfect for demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Incremental encoder cable, M23 12-pin encoder cable, SICK encoder cable, industrial encoder connector cable
Technical Specifications
- Connection type head A: Female connector, M23, 12-pin, straight
- Connection type head B: Male connector, M23, 12-pin, straight
- Connector material: Zinc die-cast, nickel-plated
- Connector color: Black
- Locking nut material: Zinc die-cast, nickel-plated
- Cable length: 5 m
- Cable wires: 11-wire
- Jacket material: PUR
- Cable diameter: 7.5 mm
- Conductor cross section: 2 x 0.5 mm² + 4 x 2 x 0.25 mm² + 1 x 0.14 mm²
- Shielding: Shielded
- Bending radius stationary position: > 5 x cable diameter
- Operating temperature: -20°C to +130°C
- Reference voltage: ≤ 30 V
- Signal type: Incremental
- Enclosure rating: IP66/IP67
- Dimensions (H x L x W): 15mm x 5000mm x 15mm
- Weight: 0.3 kg
Key Features
- Female and male M23 12-pin straight connectors
- Zinc die-cast, nickel-plated connector and locking nut
- 5 m PUR jacketed cable with 11 wires
- Shielded cable for signal integrity
- IP66/IP67 rated enclosure for dust and water protection
- Operating temperature range from -20°C to +130°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation systems
- Incremental signal transmission
- Machine control and monitoring
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable PUR jacket reduces environmental waste by extending cable life
- Shielded design minimizes electromagnetic interference, improving system efficiency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's warranty policy for details.
Available Now
The SICK DSC-2312-G05MLA3 incremental encoder cable is available for immediate purchase, ideal for industrial automation and control applications.
