Incremental Rotary Encoder SICK DFS25A-A2DAE001800 | 1800 Pulses/Rev | IP65/IP67 Rated | by SICK
The SICK DFS25A-A2DAE001800 incremental rotary encoder delivers high precision with 1,800 pulses per revolution, making it ideal for industrial automation and robotics applications. Its robust design features IP65 and IP67 ratings for dust and water protection, ensuring reliable performance in harsh environments. With a wide operating temperature range from -30°C to +85°C, this encoder is built for durability and efficiency in motion control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Pulses per revolution: 1,800
- Measuring step deviation: ±0.008° pulses 100 to 10,000
- Error limits: ±0.03°
- Communication interface: Incremental, Open Collector
- Number of signal channels: 6
- Output frequency: 150 kHz
- Load current: 30 mA
- Power consumption: 0.7 W (without load)
- Supply voltage: 8 to 30 V
- Connection type: Male connector, MS, 7-pin, radial
- Shaft diameter: 3/8 inch with flat
- Shaft length: 19 mm
- Mechanical design: Solid shaft, square flange
- Operating speed: up to 9,000 min⁻¹
- Start up torque: 0.5 Ncm at +20°C
- Operating torque: 0.3 Ncm at +20°C
- Permissible shaft loading: 80 N radial, 40 N axial
- Bearing lifetime: 3.6 x 10^9 revolutions
- Enclosure rating: IP65 shaft side, IP67 housing side
- Operating temperature range: -30°C to +85°C
- Resistance to shocks: 100 g, 11 ms
- Resistance to vibration: 30 g, 10 Hz to 2,000 Hz
- Dimensions (H x L x W): 58mm x 80mm x 58mm
- Weight: 0.4 kg
Key Features
- High resolution with 1,800 pulses per revolution
- Robust mechanical design with solid shaft and square flange
- IP65 rated shaft side and IP67 rated housing side for protection against dust and water
- Reverse polarity and short-circuit protection
- Low power consumption of 0.7 W without load
- Operating temperature range from -30°C to +85°C
- High resistance to shock (100 g) and vibration (30 g)
- 0-set function via hardware pin for easy initialization
- Communication via incremental open collector interface with 6 signal channels
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with incremental encoders and electrical safety standards to ensure proper connection and operation.
Applications
- Industrial automation and control systems
- Robotics and motion control
- Conveyor systems and material handling
- Machine tool positioning and feedback
- Safety-related monitoring in machinery
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing waste
- Low power consumption contributes to energy efficiency in industrial systems
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK DFS25A-A2DAE001800 incremental encoder is available for immediate purchase, ideal for industrial automation and safety-related applications.
