Incremental Rotary Encoder DGS80/90 | IP65 Rated | Up to 8192 Pulses | Hollow Shaft Options | by SICK
The DGS80/90 incremental rotary encoder is designed for precision in industrial automation, featuring an IP65 rating for dust and water protection and offering up to 8192 pulses per revolution. With large hollow shaft diameters of 30 mm, 42 mm, and 65 mm, it's perfect for motion control applications. Built for reliable performance, this encoder supports various communication interfaces and connection types, ensuring easy integration into your systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Incremental Rotary Encoder DGS80/90 | IP65 Rated | Up to 8192 Pulses | Hollow Shaft Options | by SICK
Brand: SICK
SKU: 1133509
Alternatively Known As: Incremental rotary encoder, hollow shaft encoder, industrial encoder, motion sensor encoder
Technical Specifications
- Pulses per revolution: up to 8,192
- Hollow shaft diameter: 30 mm or 42 mm (DGS80), 65 mm (DGS90)
- Enclosure rating: IP65
- Communication interfaces: TTL, HTL
- Connection types: M12, M23, MS (Mil-Spec) plug, cable with flying leads
- Supply voltage range: 5 V to 30 V
- Construction size (flange): Ø 81 mm
- Specialty: cable with male connector M23, 0.5 m length, customer-specific pin assignment, customized label, 24 mm collet pre-assembled
- Dimensions (H x L x W): 81mm x 50mm x 81mm
- Weight: 1.5 kg
Key Features
- Large hollow shaft diameters: up to 42 mm (DGS80) and 65 mm (DGS90)
- Pulses per revolution up to 8,192
- Enclosure rating IP65 for dust and water protection
- Communication interfaces: TTL and HTL
- Multiple connection types including M12, M23, MS (Mil-Spec) plug and cable with flying leads
- Quick and easy installation with clamping ring and universal stator couplings
- Wide selection of collets available for shaft size adjustment
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper mounting and electrical connection according to industrial standards.
Applications
- Industrial automation systems
- Asynchronous motor control
- Motion control sensors requiring large hollow shaft encoders
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP65 rated design reduces need for frequent replacements
- Energy-efficient operation supports sustainable industrial automation
Warranty Information
Standard manufacturer warranty applies; typically 1-2 years against defects.
Available Now
The SICK DGS80/DGS90 incremental encoders are available for immediate purchase, ideal for industrial automation and motor control applications.
