Incremental Rotary Encoder DGS80/90 | IP65 Enclosure | Up to 8192 Pulses | Hollow Shaft Options | by SICK
The DGS80/90 incremental rotary encoder is designed for precision in industrial automation, featuring a robust IP65 enclosure for dust and water protection. With hollow shaft diameters of up to 65 mm and a pulse count of up to 8,192, it’s perfect for motion control and speed measurement applications. Ideal for technicians and engineers, this encoder ensures reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Incremental Rotary Encoder DGS80/90 | IP65 Enclosure | Up to 8192 Pulses | Hollow Shaft Options | by SICK
Brand: SICK
SKU: 1146397
Alternatively Known As: Incremental rotary encoder, hollow shaft encoder, industrial encoder, motion sensor encoder
Technical Specifications
- Pulses per revolution: up to 8,192
- Hollow shaft diameter: 30 mm or 42 mm (DGS80), 65 mm (DGS90)
- Enclosure rating: IP65
- Communication interfaces: TTL, HTL
- Connection types: M12, M23, MS (Mil-Spec) plug and cable with flying leads
- Supply voltage range: 5 V to 30 V
- Construction size (flange): Ø 81 mm
- Specialty connection: Cable with plug, M5, 10-pin, 18" (MS3102R18-1-P)
- Dimensions (H x L x W): 81mm x 81mm x 81mm
- Weight: 1.5 kg
Key Features
- Large hollow shaft diameters: up to 42 mm (DGS80) and 65 mm (DGS90)
- Pulses per revolution up to 8,192
- Enclosure rating IP65 for dust and water protection
- Communication interfaces: TTL, HTL
- Multiple connection types including M12, M23, MS (Mil-Spec) plug and cable with flying leads
- Quick and easy installation with clamping ring and universal stator couplings
- Collets available as accessories for shaft size adjustment
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper mounting, electrical connection, and compliance with safety standards.
Applications
- Industrial automation systems
- Asynchronous motor control
- Motion control sensors
- Shaft position and speed measurement
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Durable IP65 rated design reduces need for frequent replacements
- Energy-efficient operation supports sustainable industrial automation
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK DGS80/90 incremental encoders are available for immediate purchase, ideal for industrial automation and motion control applications.
