Incremental Rotary Encoder DUV60E-D4KMHADA | 1 to 1500 Pulses/Rev | IP65 Enclosure | by SICK
The DUV60E-D4KMHADA incremental rotary encoder is designed for precise position and speed measurement in industrial automation. With adjustable pulses per revolution from 1 to 1500 and a robust IP65-rated aluminum housing, it ensures high reliability and performance in demanding environments. Ideal for conveyor systems, robotics, and material handling applications, this encoder operates efficiently across a wide temperature range of -30°C to +70°C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Pulses per revolution: 1 to 1500 (type-dependent)
- Resolution: 0.125 mm/pulse to 304.8 mm/pulse
- Measuring step: 90° electric/pulses per revolution with ±18° deviation
- Duty cycle: 0.5 ± 5%
- Initialization time: less than 5 ms
- Communication interface: Incremental TTL/HTL
- Power supply: 4.75 V to 30 V
- Max output frequency: 60 kHz
- Load current max: ≤ 30 mA per channel
- Operating speed: up to 1500 min⁻¹
- Bearing lifetime: 3.6 x 10⁹ revolutions
- Operating temperature: -30°C to +70°C
- Enclosure rating: IP65
- Shock resistance: 100 g
- Vibration resistance: 30 g, 10 Hz to 2000 Hz
- Dimensions (H x L x W): 100mm x 150mm x 150mm
- Weight: 0.9 kg
Key Features
- High reliability with MTTFD of 275 years according to EN ISO 13849-1
- Incremental communication interface with TTL/HTL signals
- Adjustable pulses per revolution from 1 to 1500
- Robust aluminum housing with IP65 enclosure rating
- Operating temperature range from -30°C to +70°C
- Reverse polarity and short-circuit protection
- Measuring wheel with 12 inch circumference made of smooth urethane plastic
- Spring arm design with under-belt flange mount for stable measurement
- Low power consumption with max 1.25 W and 120 mA no load current
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper mounting, electrical connection, and calibration for optimal performance and safety.
Applications
- Industrial automation for precise position and speed measurement
- Conveyor belt systems
- Material handling and packaging machinery
- Robotics and motion control systems
Standards & Compliance
- Complies with AS/NZS 61000 series for EMC standards
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing waste
- Low power consumption contributes to energy efficiency in industrial systems
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK DUV60E-D4KMHADA incremental encoder is available for immediate purchase, ideal for industrial automation and precise measurement applications.
