Trade Discount 17%
Dutch Clamp SEG Type 50-80 | Durable Steel | Chemical Resistant & Easy Installation | by Cabac
Dutch clamp seg type 50-80 made from durable steel—ideal for securing pipes and cables. Built for contractors and DIY enthusiasts, with easy installation for reliable support.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Dutch Clamp Seg Type 50-80 | Durable Steel Construction | Easy Installation by Matchmaster
Brand: Cabac
SKU: DC-SEG50-80
Alternatively Known As: Dutch Clamp SEG 50-80, SEG Cable Clamp 50-80, Medium Voltage Cable Clamp, High Voltage Cable Clamp, Cable Cleat SEG 50-80
Technical Specifications
- Suitable for cable diameters from 50 mm to 80 mm
- Resistant to oils, fats, chemicals, frost, heat, UV, ozone, salt, moisture, acids, and nuclear radiation
- Stackable with extra centre hole for mounting
- Self-extinguishing V-0 (UL94) rating
- Temperature range: -40°C to 120°C (225°C momentarily)
- Non-magnetic and non-conductive
- No oxidation, corrosion or sharp edges
- Dimensions (H x L x W): 50mm x 150mm x 100mm
- Weight: 0.5 kg
Key Features
- Resistant to oils, fats, aggressive chemicals, frost, heat, UV, ozone, salt, moisture, acids, and nuclear radiation
- Stackable design with extra centre hole for mounting with 1 bolt
- Self-extinguishing V-0 (UL94) and halogen free
- Temperature range from -40°C to 120°C (225°C momentarily)
- No magnetism or conductivity
- Custom mounting available and very simple installation
- No oxidation, corrosion or sharp angles
- Recyclable
- Certified in accordance with NEN-EN-IEC 61914:2009
Professional Installation Requirements
- Installation should be performed by qualified professionals to ensure proper fastening and compliance with electrical safety standards.
Applications
- Fastening of single or multicore medium and high voltage cables
- Suitable for cables with diameter from 50 mm to 80 mm
- Use in electrical installations requiring short-circuit resistant cable clamps
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Recyclable materials reduce environmental impact
- Halogen free and self-extinguishing properties enhance safety and reduce toxic emissions
Warranty Information
Lifetime of Product Warranty.
Available Now
The Cabac DUTCH CLAMP SEG TYPE 50-80 is available now for immediate purchase. Ideal for medium and high voltage cable management in industrial and electrical infrastructure applications.
