Inductive Proximity Sensor CQ4-08ENOKU1 | IP67 Rated | 100 Hz Switching Frequency | NPN Normally Closed | by SICK
The Inductive Proximity Sensor CQ4-08ENOKU1 is designed for industrial automation, featuring an IP67 enclosure for robust protection and a high switching frequency of 100 Hz. With a sensing range of 1 mm to 8 mm, this sensor is perfect for non-contact switching and position sensing in manufacturing lines, ensuring precise detection in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 12 mA
- Switching frequency: 100 Hz
- Voltage drop: ≤ 2.5 V DC
- Hysteresis: 4% to 20%
- Reproducibility: ≤ 5%
- Temperature drift of sensing range: ± 20%
- Cable: 3-wire PVC, 2 m length
- Output function: NPN normally closed
- Short-circuit and power-up pulse protection included
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Operating temperature: -20 °C to +75 °C
- Storage temperature: -40 °C to +85 °C
- Housing material: Plastic ABS
- Enclosure rating: IP67
- Dimensions (H x L x W): 39.5mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with IP67 enclosure rating for robust protection
- Sensing range from 1 mm to 8 mm with safe sensing range of 5.76 mm
- Non-flush and flush installation types available
- NPN normally closed switching output with 3-wire DC electrical wiring
- High switching frequency of 100 Hz
- Adjustment potentiometer for sensitivity tuning
- Short-circuit and power-up pulse protection included
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -20 °C to +75 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure correct wiring and sensor adjustment for optimal performance and safety.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Non-contact switching in machinery
- Safety and control systems requiring precise sensing
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Low power consumption (12 mA) supports energy-efficient operation
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK CQ4-08ENOKU1 inductive proximity sensor is available for immediate purchase, ideal for industrial automation and control applications.
