Inductive Proximity Sensor | IP68 Rated | 4mm Sensing Range | 2000Hz Switching Frequency | by SICK
The Inductive Proximity Sensor IQ12-04NPSKR8SS12 is designed for reliable object detection in industrial automation. With a robust IP68 rating and a sensing range of 4 mm, it ensures optimal performance even in harsh environments. Featuring a high switching frequency of 2,000 Hz and a PNP normally open output, this sensor is perfect for position sensing in manufacturing lines and non-contact detection applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing range Sn: 4 mm
- Safe sensing range Sa: 3.24 mm
- Switching frequency: 2,000 Hz
- Connection type: Cable with connector M8, 3-pin, 0.2 m
- Switching output: PNP, normally open (NO)
- Electrical wiring: DC 3-wire
- Enclosure rating: IP68
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 3 V
- Time delay before availability: ≤ 100 ms
- Hysteresis: 5% to 15%
- Reproducibility: ≤ 2%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- No load current: 10 mA
- Cable material: PVC
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: –25 °C to +75 °C
- Housing material: Plastic, VISTAL®
- Sensing face material: Plastic, VISTAL®
- Tightening torque, max.: ≤ 1 Nm
- Dimensions (H x L x W): 40mm x 26mm x 12mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with IP68 rating for robust protection
- Non-flush installation type with 4 mm sensing range
- High switching frequency of 2,000 Hz for fast response
- PNP switching output with normally open function
- Cable with M8, 3-pin connector for easy connection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide supply voltage range from 10 V DC to 30 V DC
- Short-circuit and power-up pulse protection included
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and mounting according to manufacturer guidelines.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Non-contact detection in harsh environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP68 housing reduces need for frequent replacements
- Low power consumption with efficient DC 3-wire electrical wiring
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK IQ12-04NPSKR8SS12 inductive sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
