Inductive Proximity Sensor IQR40-20BPPKC0K | IP68 Rated | Short-Body Design | 250 Hz Switching Frequency | by SICK
The Inductive Proximity Sensor IQR40-20BPPKC0K is designed for reliable object detection in industrial automation. With a sensing range of 20 mm and a high switching frequency of 250 Hz, this sensor is perfect for flush installation in machinery. Its IP68 rated enclosure ensures durability in challenging environments, making it ideal for welding applications and more.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 1.8 V
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 2%
- Temperature drift of sensing range: ≤ ±10% to ±15%
- Continuous current: ≤ 200 mA
- No load current: ≤ 15 mA
- Off-state current: ≤ 0.1 mA
- Magnetic field strength tolerance: ≤ 100 mT
- Protection class: II
- Housing and sensing face material: Plastic, PBT
- Switching output: PNP complementary
- Connection type: Male connector M12, 4-pin
- Switching frequency: 250 Hz
- Enclosure rating: IP68
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: –30 °C to +85 °C
- MTTFD: 139 years
- Mission time: 20 years
- Short-circuit protection: Yes
- Dimensions (H x L x W): 40mm x 65mm x 40mm
- Weight: 0.1 kg
Key Features
- Short-body housing design
- Sensing range of 20 mm with safe sensing range of 16.2 mm
- High switching frequency of 250 Hz
- PNP complementary switching output
- IP68 rated enclosure for dust and water resistance
- Magnetic-field-resistant with reduction factor 1
- Clamp-lock mounting system included
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from –30 °C to +85 °C
- Short-circuit protection included
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is recommended to ensure proper wiring and mounting for optimal sensor performance and safety.
Applications
- Industrial automation for object detection
- Welding range and difficult application conditions
- Flush installation in machinery and equipment
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP68 housing reduces need for frequent replacements, minimizing waste
- Energy-efficient operation with low current consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK IQR40-20BPPKC0K inductive sensor is available for immediate purchase, ideal for industrial automation and machinery applications requiring reliable object detection.
