Inductive Proximity Sensor M12 60mm | IP67 Rated | 1000 Hz Switching Frequency | Short-Body Metal Housing | by SICK
The Inductive Proximity Sensor M12 60mm is designed for precise object detection in industrial automation, featuring a sensing range of up to 60 mm and a high switching frequency of 1,000 Hz. With its robust IP67 rated metal housing, this sensor is built to withstand harsh environments, making it ideal for manufacturing lines and safety control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Inductive Proximity Sensor M12 60mm | IP67 Rated | 1000 Hz Switching Frequency | Short-Body Metal Housing | by SICK
Brand: SICK
SKU: 1040065
Alternatively Known As: Inductive Proximity Sensor M12 60mm, SICK Proximity Sensor MM12-60APO, M12 Inductive Sensor 60mm Range
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M12 x 1
- Diameter: 12 mm
- Sensing range Sn: 0 mm to 60 mm
- Safe sensing range Sa: 48.6 mm
- Magnetic sensitivity: 1 mT
- Switching frequency: 1,000 Hz
- Connection type: Cable, 3-wire, 2 m PUR
- Switching output: PNP, NC function
- Electrical wiring: DC 3-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Current consumption: 10 mA
- Time delay before availability: ≤ 20 ms
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- Reverse polarity protection: Yes
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: -25 °C to +75 °C
- Housing length: 48 mm
- Thread length: 28 mm
- Tightening torque max: 15 Nm
- Dimensions (H x L x W): 12mm x 48mm x 12mm
- Weight: 0.1 kg
Key Features
- Short-body housing with M12 x 1 thread size
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- High switching frequency of 1,000 Hz
- PNP switching output with NC output function
- IP67 rated enclosure for dust and water protection
- Robust metal nickel-plated brass housing
- Cable connection type with 3-wire, 2 m PUR cable
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical wiring and sensor mounting to ensure proper operation and safety.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Safety and control systems requiring reliable proximity sensing
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal housing extends product life reducing waste
- Low power consumption with efficient switching output
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MM12-60APO-ZUK inductive proximity sensor is available for immediate purchase, ideal for industrial automation and position sensing applications.
