Inductive Proximity Sensor M12 | NPN Normally Open | IP67 Rated | 60mm Sensing Range | by SICK
The Inductive Proximity Sensor M12 is designed for reliable object detection in industrial automation, featuring a sensing range of up to 60 mm and a high switching frequency of 1,000 Hz. With its durable metal housing and IP67 rating, this sensor is perfect for harsh environments, ensuring safety and efficiency in manufacturing lines and machinery control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Inductive Proximity Sensor M12 | NPN Normally Open | IP67 Rated | 60mm Sensing Range | by SICK
Brand: SICK
SKU: 1040026
Alternatively Known As: Inductive Proximity Sensor M12, SICK Proximity Sensor 60mm, NPN Proximity Switch, Metal Body Proximity Sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 10 mA
- Switching output: NPN, normally open
- Switching frequency: 1,000 Hz
- Sensing range Sn: 0 to 60 mm
- Safe sensing range Sa: 48.6 mm
- Voltage drop: ≤ 2 V
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift: ±10%
- Cable: PUR, 3-wire, 2 m length
- Protection: Reverse polarity, short-circuit, power-up pulse
- Enclosure rating: IP67
- Shock resistance: 30 g, 11 ms
- Operating temperature: -25 °C to +75 °C
- Dimensions (H x L x W): 12mm x 48mm x 12mm
- Weight: 0.1 kg
Key Features
- Short-body metal housing with nickel-plated brass
- M12 x 1 thread size with 48 mm housing length
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- High switching frequency of 1,000 Hz
- NPN normally open switching output
- Cable connection, 3-wire, 2 m length
- IP67 rated enclosure for dust and water protection
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and secure mounting according to industrial safety standards.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Safety and control systems in machinery
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal housing extends product life reducing waste
- Low power consumption of 10 mA supports energy efficiency
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MM12-60ANS-ZUK inductive proximity sensor is available for immediate purchase, ideal for industrial automation and machinery safety applications.
