Inductive Proximity Sensor M30 | 16mm Sensing Range | IP67/IP68/IP69K Rated | by SICK
The Inductive Proximity Sensor M30 is designed for reliable object detection in industrial automation, featuring a sensing range of up to 16mm and an enclosure rating of IP67/IP68/IP69K for harsh environments. With a PNP complementary output and a switching frequency of 50 Hz, it's perfect for machine safety and control systems, ensuring precise position sensing in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 36 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP complementary
- Switching frequency: 50 Hz
- Cable: 4-wire, 2 m PVC cable with 0.34 mm² conductor size
- Voltage drop: ≤ 2 V DC
- Hysteresis: 3% to 20%
- Reproducibility: ≤ 5%
- Temperature drift: ±10%
- Enclosure rating: IP67, IP68, IP69K
- Shock resistance: 30 g, 11 ms shocks per EN 60068-2-27
- Vibration resistance: 10 Hz to 150 Hz, 1 mm / 15 g per EN 60068-2-6
- Housing material: Plastic, PBT
- Thread length: 59.5 mm
- Tightening torque max: ≤ 7.5 Nm
- Communication interface: IO-Link V1.1, COM2 (38.4 kBaud)
- Dimensions (H x L x W): 81mm x 81mm x 30mm
- Weight: 0.1 kg
Key Features
- Metric housing with M30 x 1.5 thread size
- Sensing range up to 16 mm with safe sensing range of 12.24 mm
- Flush installation type
- Switching frequency of 50 Hz with PNP complementary output
- Wire configurable output characteristic
- Visual adjustment indicator for sensitivity
- Enclosure rating IP67, IP68, and IP69K for harsh environments
- Shock and vibration resistant according to EN 60068 standards
- Operating temperature range from -30°C to +85°C
- IO-Link V1.1 communication interface with COM2 (38.4 kBaud)
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and configuration to ensure proper operation and safety.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Position sensing in manufacturing processes
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Energy-efficient operation minimizes power consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK CMB30-16BPPEW2SA00 inductive proximity sensor is available for immediate purchase, ideal for industrial automation and machine safety applications.
