Inductive Proximity Sensor M30 | NPN Output | IP68 & IP69K Rated | Flush Mount | by SICK
The Inductive Proximity Sensor M30 is designed for reliable object detection in industrial automation, featuring a sensing range of 3 mm to 16 mm and NPN switching output. With an IP68 and IP69K rating, it offers high protection against dust and water, making it ideal for machine safety and control systems in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 36 V DC
- Current consumption: 12 mA
- Switching frequency: 50 Hz
- Voltage drop: ≤ 2 V DC
- Hysteresis: 3% to 20%
- Reproducibility: ≤ 5%
- Temperature drift: ± 10%
- Cable: 4-wire PVC, 2 m length, 0.34 mm² conductor size
- Enclosure rating: IP68 and IP69K
- Housing material: Plastic, PBT
- Thread length: 59.5 mm
- Tightening torque max: ≤ 7.5 Nm
- EMC compliant according to EN 60947-5-2
- Shock and vibration resistance according to EN 60068
- Short-circuit and power-up pulse protection included
- Dimensions (H x L x W): 30mm x 81mm x 30mm
- Weight: 0.15 kg
Key Features
- Metric housing with M30 x 1.5 thread size
- Sensing range from 3 mm to 16 mm
- Flush installation type
- NPN switching output with complementary function
- Wire configurable output characteristic
- IP68 and IP69K rated for high protection against dust and water
- Shock and vibration resistant according to EN 60068
- Short-circuit and power-up pulse protection included
- Operating temperature range from -30°C to +85°C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical wiring and sensor mounting to ensure proper function and safety.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Position sensing in manufacturing processes
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Energy-efficient operation minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK CM30-16BNP-EW1 Inductive Proximity Sensor is available for immediate purchase, ideal for industrial automation and machine safety applications.
