Inductive Proximity Sensor M30 | Sensing Range 2mm to 16mm | IP67 Rated | by SICK
The Inductive Proximity Sensor M30 is designed for reliable object detection in industrial automation. With a sensing range of 2mm to 16mm and an IP67 rating, it ensures durability in harsh environments. Ideal for machine safety and control systems, this sensor features a configurable output function and low power consumption, making it perfect for various manufacturing applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 20 V AC to 250 V AC
- Current consumption: 10 mA
- Voltage drop: ≤ 10 V DC
- Switching frequency: 10 Hz
- Hysteresis: 4% to 20%
- Reproducibility: ≤ 5%
- Temperature drift: ±10%
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Ambient operating temperature: -25°C to +80°C
- Housing material: Plastic, PBT
- Cable material: PVC, conductor size 0.5 mm²
- Power-up pulse protection included
- Tightening torque max: ≤ 7.5 Nm
- Dimensions (H x L x W): 63.6mm x 63.6mm x 30mm
- Weight: 0.1 kg
Key Features
- Metric housing with M30 x 1.5 thread size
- Sensing range from 2 mm to 16 mm
- Flush installation type
- Switching frequency of 10 Hz
- Cable connection, 2-wire, 2 m length
- Output function configurable as NC or NO
- Electrical wiring: AC 2-wire
- Sensitivity adjustable via 11-turn potentiometer
- Enclosure rating IP67 according to EN 60529
- Includes mounting nuts and screwdriver for adjustment
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical wiring and sensor mounting to ensure proper function and safety.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Position sensing in manufacturing processes
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP67 rated housing reduces environmental damage and extends product life
- Low power consumption with efficient AC 2-wire design
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK CM30-16BAP-KW1 inductive proximity sensor is available for immediate purchase, ideal for industrial automation and safety control applications.
