Inductive Proximity Sensor | PNP Normally Open | IP67 Rated | 5mm Sensing Range | by SICK
The Inductive Proximity Sensor IQE17-05NPSKW2S is designed for reliable object detection in industrial automation. With a PNP normally open output and a sensing range of 5 mm, it ensures fast response times with a high switching frequency of 1,000 Hz. Its IP67 rated enclosure provides excellent protection against dust and water, making it ideal for various applications in manufacturing and control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Time delay before availability: ≤ 100 ms
- Hysteresis: 5% to 15%
- Reproducibility: ≤ 2%
- Temperature drift of sensing range: ± 10%
- Continuous current Ia: ≤ 200 mA
- No load current: 10 mA
- Switching output: PNP normally open
- Switching frequency: 1,000 Hz
- Cable length: 2 m PVC cable
- Enclosure rating: IP67
- Housing material: Plastic
- Tightening torque max: 0.9 Nm
- EMC compliant according to EN 60947-5-2
- Short-circuit and power-up pulse protection included
- Operating temperature range: -25 °C to +75 °C
- Dimensions (H x L x W): 17mm x 29.5mm x 17mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with compact dimensions of 17 mm x 17 mm x 29.5 mm
- Non-flush installation type for versatile mounting
- Sensing range of 5 mm with safe sensing range of 4.05 mm
- High switching frequency of 1,000 Hz for fast response
- PNP normally open switching output with DC 3-wire electrical wiring
- IP67 rated enclosure for dust and water protection
- Short-circuit and power-up pulse protection included
- Wide ambient operating temperature range from -25 °C to +75 °C
- Cable connection type with 2 m PVC cable
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical sensor wiring and mounting to ensure proper function and safety.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Non-contact switching in machinery
- Safety and control systems requiring precise sensing
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP67 rated housing reduces replacement frequency and waste
- Low power consumption with efficient DC 3-wire design
- Robust design minimizes environmental impact through extended service life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK IQE17-05NPSKW2S inductive sensor is available for immediate purchase, ideal for industrial automation and control applications requiring reliable object detection.
