Inductive Proximity Sensor | Short-Body Design | IP68 Rated | 45mm Sensing Range | by SICK
The Inductive Proximity Sensor is designed for reliable object detection in industrial automation, featuring a short-body design and a sensing range of 45 mm. With an IP68 rated enclosure, it withstands harsh environments, making it ideal for welding and non-flush mounting applications. This sensor operates efficiently across a wide temperature range of -30 °C to +85 °C, ensuring durability and performance in demanding conditions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 1.8 V
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 2%
- Temperature drift of sensing range: ≤ ±10% to ±15%
- Continuous current: ≤ 200 mA
- No load current: ≤ 15 mA
- Off-state current: ≤ 0.1 mA
- Short-circuit protection included
- Magnetic field strength tolerance: ≤ 100 mT
- Housing and sensing face material: Plastic, PBT
- Protection class: II
- Switching output: PNP, normally open
- Connection type: Male connector M12, 4-pin
- Switching frequency: 250 Hz
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: -30 °C to +85 °C
- Dimensions (H x L x W): 40mm x 65mm x 40mm
- Weight: 0.1 kg
Key Features
- Short-body housing design
- Non-flush installation type
- Sensing range of 45 mm with safe sensing range of 36.4 mm
- High switching frequency of 250 Hz
- PNP switching output with normally open function
- IP68 rated enclosure for dust and water resistance
- Magnetic-field-resistant with reduction factor 1
- Clamp-lock mounting system included
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -30 °C to +85 °C
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and mounting according to safety standards.
Applications
- Industrial automation for object detection
- Welding range and difficult application conditions
- Non-flush mounting sensing applications
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP68 housing reduces need for frequent replacements
- Energy-efficient operation with low current consumption
- Supports sustainable industrial automation by enhancing process reliability
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK IQR40-45NPSKC0K inductive proximity sensor is available for immediate purchase, ideal for industrial automation and sensing applications in harsh environments.
