Inductive Proximity Sensor | Short-body Design | IP68 Rated | PNP Output | by SICK
The Inductive Proximity Sensor is designed for reliable object detection in industrial automation, featuring a short-body housing and an IP68 rated enclosure for high protection. With a sensing range of 20 mm and a switching frequency of 250 Hz, it's perfect for flush installation in machinery and equipment, ensuring durability and efficiency in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 1.8 V
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 2%
- Temperature drift of sensing range: ≤ ±10% to ±15%
- Continuous current: ≤ 200 mA
- No load current: ≤ 15 mA
- Off-state current: ≤ 0.1 mA
- Magnetic field strength tolerance: ≤ 100 mT
- Housing material: Plastic, PBT
- Sensing face material: Plastic, PBT
- Protection class: II
- Switching output: PNP, Normally Open (NO)
- Connection type: Male connector M12, 4-pin
- Switching frequency: 250 Hz
- Enclosure rating: IP68
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- MTTFD: 139 years
- Mission time: 20 years
- Short-circuit protection: Yes
- Dimensions (H x L x W): 40mm x 65mm x 40mm
- Weight: 0.1 kg
Key Features
- Short-body housing design
- Sensing range of 20 mm with safe sensing range of 16.2 mm
- Flush installation type
- Switching frequency of 250 Hz
- PNP switching output with NO function
- Male connector M12, 4-pin connection
- IP68 rated enclosure for high protection
- Magnetic-field-resistant with reduction factor 1
- Clamp-lock mounting system included
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature from –30 °C to +85 °C
- Short-circuit protection included
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is recommended to ensure proper wiring and mounting according to safety standards.
Applications
- Industrial automation for object detection
- Welding range and difficult application conditions
- Flush installation in machinery and equipment
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Energy-efficient operation with low current consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK IQR40-20BPSKC0K inductive sensor is available for immediate purchase, ideal for industrial automation and machinery applications requiring reliable object detection.
