Industrial Ethernet Cable M12 to RJ45 Cat6A 0.3m SICK

BRAND: SICK
SKU: 2142050
$75.90 List price: $95.40
+ −
30 Days Return Electricians Unlock Trade Access
Built for industrial Ethernet networks and data transmission in harsh environments, this SICK cable has male RJ45, 8-pin, straight connectors on both ends. The 0.3m shielded CAT6A cable supports data rates up to 10 Gbit/s, with a halogen-free PUR jacket and TPU connectors rated flame retardant to UL 1581. It's built to AS/NZS 60950 safety standards for IT and communication equipment. Spec sheet and application notes are available in the section below.
Technical Specifications
  • Connection type head A: Male connector, RJ45, 8-pin, straight
  • Connection type head B: Male connector, RJ45, 8-pin, straight
  • Connector material: TPU
  • Connector color: Black
  • Cable length: 0.3 m
  • Cable type: 8-wire, PUR, halogen-free
  • Jacket material: PUR, halogen-free
  • Jacket color: Green
  • Cable diameter: 6.4 mm
  • Conductor cross section: 0.14 mm²
  • Shielding: Shielded
  • Bending radius flexible use: > 10 x cable diameter
  • Bending radius stationary position: > 8 x cable diameter
  • Nominal voltage: 125 V AC
  • Test voltage: 1,000 V AC
  • Reference voltage: 48 V AC / 60 V DC
  • Signal type: Ethernet, Gigabit Ethernet
  • Transmission characteristics: CAT6A
  • Data transmission rate: ≤ 10 Gbit/s
  • Operating temperature stationary position: -40 °C to +80 °C
  • Operating temperature head: -25 °C to +85 °C
  • Contamination rating: 3
  • Insulation resistance: > 100 mΩ
  • Thermal resistance: Flame retardant acc. to UL 1581 Section 1090, 1100 (FT2), 1080 (VW-1) / IEC 60332-1-2
  • Enclosure rating: IP20
  • Dimensions (H x L x W): 6mm x 300mm x 6mm
  • Weight: 0.1 kg
Key Features
  • Shielded CAT6A cable supporting data rates up to 10 Gbit/s
  • Male RJ45 8-pin straight connectors on both ends
  • Cable jacket and connectors made from halogen-free PUR and TPU materials
  • Flame retardant cable compliant with UL 1581 standards
  • Operating temperature range from -40°C to +85°C
  • IP20 enclosure rating suitable for industrial environments
Professional Installation Requirements
  • Installation by qualified personnel is recommended to ensure proper connection and compliance with safety standards.
Applications
  • Industrial Ethernet networks
  • Zones with oils and lubricants
  • Data transmission in harsh environments
Standards & Compliance
  • AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Halogen-free cable materials reduce toxic emissions in case of fire
  • Flame retardant properties enhance safety and reduce environmental hazards
Warranty Information

Standard manufacturer warranty applies. Please refer to SICK for detailed warranty terms.

Available Now

The SICK YMRJA8-C30EG1MRJA8 Ethernet cable is available for immediate purchase, ideal for industrial Ethernet networking applications requiring robust and reliable data transmission.


FAQ

Q: What connectors does this cable use?

A: It has male RJ45, 8-pin, straight connectors on both ends, made from halogen-free PUR and TPU materials.

Q: What data rate does this cable support?

A: It supports transmission rates up to 10 Gbit/s over shielded CAT6A conductors, and it's backed by SCHNAP's 30-day returns policy for added purchasing confidence.


For M12-terminated CAT6A runs elsewhere on the network, an angled M12 to RJ45 Cat6A ethernet cable offers a mixed connector configuration.

An M12 push-pull Cat6A ethernet cable is also available for a fully M12-to-RJ45 shielded configuration.

The wider industrial ethernet and fieldbus cable range covers additional lengths and connector configurations.

Order with confidence — SCHNAP offers a 30-day return policy on electrical products.
