Industrial Plug 15A | 32V DC | IP66 Rated | Electric Orange by Clipsal

BRAND: Clipsal
SKU: 56P215/32-EO
$80.50 List price: $120.80
+
Industrial plug with 15A current and 32V DC voltage—ideal for utility and small commercial applications. Built for durability, with IP66 rating for dust and water protection.

Product Name/Title: Clipsal - 56 Series, Plug Top, Straight, 2 Polarised PIN, 15A, 32V, IP66 - Electric Orange

Brand: Clipsal

SKU: 56P215/32-EO

Alternatively Known As: Industrial Plug, 15A Plug, IP66 Plug

Technical Specifications
  • Rated current: 15A
  • Rated operational voltage: 32V DC
  • Material: Polycarbonate housing
  • Connections: Screw terminal 1.5-1.5 mm²
  • Cable entry: Cable gland
  • Pin arrangement: E
  • Ambient temperature range: -25 to 75 °C
  • Dimensions (H x L x W): 67mm x 112.5mm x 67mm
  • Weight: 0.12 kg
Key Features
  • IP66 rated for protection against dust and water.
  • Designed for industrial applications with a robust build.
Professional Installation Requirements
  • Professional installation is recommended for optimal safety.
Applications
  • Utility industry
  • Small commercial
Standards & Compliance
  • Complies with AS/NZS 3112 and AS 60529 for safety and performance.
Environmental Benefits
  • Compliant with RoHS directives, ensuring reduced environmental impact.
Warranty Information

Standard warranty applies.

Available Now

The Clipsal 56 Series Plug Top is available now for immediate purchase. Ideal for industrial and small commercial applications.

56P215%252F32-EO (56P215_2F32-EO, 212 Kb) [Download]
