Industrial Socket Outlet 3P+E | 90A 440V | IP66 Rated | Polyamide by NHP
Industrial socket outlet with 3P+E configuration and 90A 440V capacity—ideal for heavy machinery and high power applications. Built for durability with IP66 protection and polyamide construction.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PROCONECT 3PS63 Socket Outlet, 3P+E, 90A (AC23 63A) 440V AC
Brand: NHP
SKU: 3PS6D30E01
Alternatively Known As: High Current Socket Outlet, 3 Phase Socket, Industrial Socket
Technical Specifications
- Amperage: 90 A
- Voltage: 380-440 V
- Contact Configuration: 3P+E
- Construction Type: Outlet
- Material Insulation Body: Polyamide (PA)
- Contact Material: Other
- Material Screw: Stainless steel
- Degree of Protection: IP66
- Nominal Tightening Torque: 4 Nm
- Operating Temperature: -30-60 °C
- Dimensions (H x L x W): 100mm x 115mm x 100mm
- Weight: 0.64 kg
Key Features
- 3P+E configuration for three-phase power supply.
- IP66 rated for protection against dust and water ingress.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Heavy machinery and equipment
- Commercial: High power applications requiring robust connections
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The PROCONECT 3PS63 Socket Outlet is available now for immediate purchase. Ideal for industrial and commercial applications requiring high power connections.
