Industrial Steel Enclosure | 2000Hx800Wx500D | IP66 Rating | Glass Viewing Window by B&R Enclosures

SKU: IP77295/WG
$6,704.70 List price: $8,427.10
Free pick up (over 25 kg)
For delivery quote message
Industrial steel enclosure with IP66 protection and glass viewing window—ideal for small motor control and lighting applications. Built for durability, with C rail mountings and stainless steel hinges for easy access.

Product Name/Title: Monarch IP 2000Hx800Wx500D IP66 St 7032 VW Glass

Brand: B&R Enclosures

SKU: IP77295/WG

Alternatively Known As: Monarch IP Enclosure, Industrial Steel Enclosure, IP66 Enclosure

Technical Specifications
  • 1.6mm thick zinc coated steel
  • 1.6mm steel gland plate (brass available as an option)
  • Polyurethane gasket (formed in place)
  • Pebble Grey (RAL7032) or Ripple Orange (X15) powdercoated finish
  • 5.4mm thick glass viewing window
  • Dimensions (H x L x W): 800mm x 500mm x 2000mm
  • Weight: 50 kg
Key Features
  • IP66 protection rating
  • C rail mountings for equipment
  • Glass Viewing Window
  • 3 point locking on models of 600mm high and above
  • Stainless steel hinges and hinge pins for easy door opening
Professional Installation Requirements
  • Professional installation by a qualified technician is recommended for optimal performance.
Applications
  • Small motor control applications
  • Lighting
  • CT metering
  • Small switchboards
Standards & Compliance
  • Complies with AS/NZS 61439 for low-voltage switchgear and controlgear assemblies.
  • Region D wind rated to AS1170.2-2002 for structural design actions.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Monarch IP – Viewing Window (ZS) is available now for immediate purchase. Ideal for industrial applications requiring robust and flexible enclosures.

Specification Sheet (, 440 Kb) [Download]

Specification Sheet (, 439 Kb) [Download]
