Insulated Cable End 1.5mm² DIN | Tin-Plated Copper | Red Insulation | by Clipsal
The Insulated Cable End 1.5mm² DIN is designed for secure and insulated cable termination, featuring a tin-plated copper construction with a red polypropylene sleeve. Ideal for electrical panel wiring and industrial control panels, this ferrule prevents wire strand fraying and improves connection reliability, ensuring compliance with DIN standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Insulated Cable End 1.5mm² DIN | Tin-Plated Copper | Red Insulation | by Clipsal
Brand: Clipsal
SKU: SCHDZ5CA015D
Alternatively Known As: Cable ferrule, wire end ferrule, insulated wire end terminal, DIN cable end, 1.5mm² ferrule
Technical Specifications
- Cable size: 1.5mm²
- Material: Tin-plated copper with insulated sleeve
- Insulation: Polypropylene
- Standard: DIN 46228/4
- Colour: Red
- Temperature rating: -40°C to +105°C
- Voltage rating: 600V
- Dimensions (H x L x W): 15mm x 15mm x 2mm
- Weight: 0.1 kg
Key Features
- Provides secure and insulated cable termination
- Suitable for 1.5mm² cables
- DIN standard compliant
- Prevents wire strand fraying
- Improves connection reliability
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Electrical panel wiring
- Industrial control panels
- Switchboards
- General electrical installations requiring secure cable termination
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reduces risk of electrical faults, minimizing maintenance and waste
- Improves electrical efficiency by ensuring secure connections
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Insulated Cable End 1.5mm² DIN (SCHDZ5CA015D) is available for immediate purchase. Ideal for electrical panel wiring and secure cable terminations in residential, commercial, and industrial applications.
