Insulation Monitoring Module 4 | 24-240V AC/DC | 1kΩ to 1MΩ Monitoring Range | Compact DIN Rail Mount | @Quantity of 1 | by Clipsal
The Insulation Monitoring Module 4 continuously monitors insulation resistance in electrical systems, with a wide voltage range of 24-240V AC/DC and a monitoring range from 1kΩ to 1MΩ. Designed for industrial and commercial applications, it features quick response times and LED indicators for easy diagnostics, ensuring early detection of insulation faults to prevent equipment damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Insulation Monitoring Module 4 | 24-240V AC/DC | 1kΩ to 1MΩ Monitoring Range | Compact DIN Rail Mount | @Quantity of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV429460
Alternatively Known As: Insulation Resistance Monitor, Insulation Fault Detector, Clipsal IMD, Electrical Insulation Monitoring Device
Technical Specifications
- Rated voltage: 24-240V AC/DC
- Monitoring range: 1kΩ to 1MΩ
- Response time: <1s
- Mounting: DIN rail
- Output: Relay contact for alarm signaling
- LED indicators: Status and fault display
- Operating temperature: -20°C to +55°C
- Dimensions (H x L x W): 90mm x 70mm x 36mm
- Weight: 0.25 kg
Key Features
- Continuously monitors insulation resistance in electrical systems
- Early detection of insulation faults to prevent equipment damage
- Compact DIN rail mountable design
- LED status indicators for quick diagnostics
- Compatible with low voltage and control circuits
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and manufacturer instructions.
Applications
- Industrial electrical panels
- Commercial switchboards
- Critical infrastructure monitoring
- Hospitals and medical facilities
- Data centers
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Prevents electrical faults that could lead to hazardous incidents or energy waste
- Supports proactive maintenance, reducing unnecessary equipment replacement
- Enhances system reliability, minimizing downtime and resource consumption
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Insulation Monitoring Module 4 (SCHLV429460) is available for immediate purchase. Ideal for industrial and commercial electrical safety monitoring applications.
