Interface Relay 6A 2CO | Spring Clamp Connection | 24V DC | Silver Contacts by NHP
Interface relay with 6A 2CO and spring clamp connection—ideal for industrial automation systems. Built for control circuits, with LED indication and 100,000 electrical cycles.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 700-HL Interface Relay 6A 2CO with Spring Clamp Connection 24V DC Silver Contacts
Brand: NHP
SKU: 700HLT22Z24
Alternatively Known As: 700-HL Relay, Interface Relay, Switching Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Rated Switching Power at AC 1: 2500 VA
- Rated Switching Power at AC 15 (230 V): 690 VA
- Breaking Capacity at DC 1 (30 V): 10 A
- Control Supply Voltage (AC 50 Hz): 24 V
- Control Supply Voltage (DC): 24 V
- Control Supply Voltage (AC 60 Hz): 24 V
- Electrical Life at Un in Service: 100,000 cycles
- Material Contact: Silver tin-oxide
- Degree of Protection: IP20
- Operating Temperature: -40 to 55 °C
- Dimensions (H x L x W): 93mm x 76mm x 62mm
- Weight: 0.5 kg
Key Features
- 10 A nominal current with 2 changeover contacts.
- Spring clamp connection for easy installation.
- LED indication for operational status.
- Rated for 100,000 electrical cycles.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial automation systems
- Control circuits
- Signal switching
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 700-HL Interface Relay is available now for immediate purchase, ideal for industrial automation and control applications.
