IO-Link Proximity Sensor | Small Housing Design | IP67 Rated | 15 kHz Switching Frequency | by SICK
The IO-Link Proximity Sensor is designed for industrial automation, featuring a small housing design and an IP67 rating for dust and water resistance. With a sensing distance of up to 12.5 mm and a fast switching frequency of 15 kHz, it's perfect for precise object detection and position sensing in manufacturing lines. Built for reliability, this sensor ensures low power consumption and easy integration with a male M8 connector.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 12 V DC to 24 V DC
- Ripple: ≤ 5 V pp
- Current consumption: < 50 mA
- Switching frequency: 15 kHz
- Response time: 32 µs
- Jitter: 15 µs
- Switching output: PNP with max output current 50 mA
- Switching mode: Light/dark switching
- Retention time: 28 ms non-volatile memory
- Time delay: Switch-off delay 520 ms via IO-Link
- Protection class: III
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Enclosure rating: IP67
- Operating temperature: -10°C to +55°C
- Storage temperature: -20°C to +75°C
- Connection type: Male M8, 4-pin connector
- Light source: White LED
- Light spot size: Ø 2 mm at 12.5 mm sensing distance
- Data transmission rate: 38.4 kbit/s (COM2)
- Cycle time: 2.3 ms
- Process data length: 16 Bit
- Dimensions (H x L x W): 31.5mm x 21mm x 12mm
- Weight: 0.1 kg
Key Features
- Small housing design measuring 12 mm x 31.5 mm x 21 mm
- Sensing distance up to 12.5 mm with ±3 mm tolerance
- White LED light source with round light spot of 2 mm diameter
- Adjustable via cable, IO-Link, and teach-in button with 2-point teach-in modes
- Dual digital PNP outputs with switching frequency of 15 kHz
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water resistance
- Operating temperature range from -10°C to +55°C
- Male M8 4-pin connector for easy integration
- Green and yellow LED indicators for power and output status
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and configuration via IO-Link.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Quality control systems requiring precise sensing
- Integration in automated machinery with IO-Link communication
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with less than 50 mA current draw
- Durable ABS and PMMA materials extend product lifespan reducing waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK KTM-MP317A1P sensor is available for immediate purchase, ideal for industrial automation and precise sensing applications.
