Trade Discount 25%
Isolator Switch 1 Pole 25A | DIN Rail Mount | IP20 Protection
Isolator switch with 1 pole and 25A capacity—ideal for lighting and machine switching. Built for versatility, with DIN rail mount and IP20 protection for secure installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Isolator Switch 1 Pole 25A | DIN Rail Mount | IP20 Protection
SKU: 4PS25CO
Alternatively Known As: DIN Rail Isolator Switch, Single Pole Isolator, 25 Amp Isolator, Changeover Switch 25A
Technical Specifications
- Rated operation voltage: 415 V AC
- Rated permanent current: 25 A
- Number of poles: 1
- Connection type: DIN Rail Connection
- Degree of protection: IP20
- Legend: Night/Off/Day
- Module width: 18 mm
- Dimensions (H x L x W): 80mm x 70mm x 18mm
- Weight: 0.1 kg
Key Features
- DIN rail mount isolator switch
- Single pole, one module wide (18mm)
- Rated for 500V and 25A
- Incoming and outgoing terminals accommodate copper conductors up to 16 sq mm
- Night, off, day switching for lighting control
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
- Switching of luminaries with daylight supplement in internal lighting
- Auto, off, manual switching of machines
- Auxiliary, off, mains switching of small stand-by generators
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables efficient control of lighting and machinery to reduce energy consumption
- Supports integration with energy-saving lighting systems
Warranty Information
Standard manufacturer warranty applies. Please refer to Clipsal warranty terms for details.
Available Now
The Clipsal Max 4 Isolator Switch 1 Pole 25A DIN Rail Mount with IP20 protection is available now for immediate purchase. Ideal for industrial and commercial electrical control applications.
